Specifications:
-Microcomputer control
-ESU-L2000 (LEEP) generator adopts LEEP which specializing in gynecological intrauterine event, increasing the accuracy, controllability, security of the surgery.
-Dealing with some kinds of pathological changes in obstetric and gynecology,for example, cutting, electrocoagulation, cervical erosion, and some kinds of surgery that fit in peritoneoscope.
-Different electrodes have different effects in coagulation.
-An optional smoke evacuation system is available.
-Particular illuminating ESU pencil can increase the clarity of wound healing.
Technical Specifications
Power: 220V±22V(110V±11V), 50Hz±1Hz
Operating frequency: 360～460kHz
Power rating: 880VA±10％
Five working modes:
--Monopolar Cut
a) Cut1 (pure cut)：1W～200W( Load 500Ω)
b) Cut2 (Blend1)：1W～150W(Load 500Ω)
c) Cut3 (Blend2)：1W～100W (Load 500Ω)
--Monopolar Coag
d) Coagulation1(Spray Coag)：1W～120W( Load 500Ω)
e) Coagulation2(Forced Coag)：1W～80W( Load 500Ω)
--Power Consumption : ≦880VA(Cutting function 200W)
Surgical Smoke Evacuation:
-Blowing rate: 100 l/min @ 6mm tube
-Noise: <60dB(A)
-Start Control: Manus/Foot/Synchronize
-Suction Adjust: 10%~100%
-Stop delay time: 0~60s
-AC Power: AC90~250V, 50Hz
-Power consumption: < 350W
-Filter Characteristics: 99.999% @ 0.1-0.2μm
-Active Carbon: 97% @ 1 year
Packing List:
| Mainframe | 1set |
| Electrosurgical pencil | 3pieces |
| Illuminating electrosurgical pencil | 2pieces |
| Electrosurgical pad | 10 pieces |
| Electrosurgical pad cable | 1piece |
| Foot switch | 1set |
| Electrodes | 1case(10pieces) |
| Tip clean sponge | 1piece |
| Fuse | 3pieces |
| Power cord | 1piece |
| Operating manual | 1book |
