| Model | AFP-500 Enteral Feeding Pump |
| Flow rate range | 1~400 ml/h |
| Volume to be infused (VTBI) | 0 ~ 9999 ml |
| Volume Infused (∑) | 0 ~36000 ml |
| Infusion accuracy | ±10% |
| Applicable feeding bag | Support a wide variety brands of feeding bag |
| Bolus rate | 400 ml/h |
| Occlusion pressure | 3 adjustable occlusion pressure settings: low, middle and high |
| Alarms | Visual and audible alarms: Door Open, Occlusion, Infusion completion, infusion near over, empty, Start reminder function, Low Battery, Battery depleted, malfunction etc. |
| Computer Interface | RS232 |
| History records | 2000 history records |
| Power supply | AC:100~240V,50/60Hz DC:12V ±1V |
| Battery | Rechargeable lithium polymer battery,7.4V,2100mAh
Can operate for more than 3 hours after fully charged at 25ml/h. |
| Recharge time | 10hs recharging when machine is turned on, 3hs recharging when machine is off. |
| Power consumption | 25VA |
| Classification | Class I, type CF |
| Water Proof Level | IP×3 |
| Mode of operation | continuous |
| Dimensions | 145×100×120 mm (length×width×height) |
| weight | ≤1.4kg |
| Operating conditions | Temperature:5℃~40℃, relative humidity: 10~95%, air pressure: 86～106kPa |
| Transport conditions | Temperature -20~+60℃, relative humidity: 10~95%, air pressure:50~106kPa |
| Storage conditions | Temperature: -20℃ ~ +45℃, relative humidity: 10~95%, air pressure: 50～106kPa |
