Vertical Pressure Steam Sterilizer ME-LS-35HD

Share
documents & resoures

Vertical Pressure Steam Sterilizer ME-LS-35HD ME-LS-50HD ME-LS-75HD ME-LS-100HD

                                                    LCD display automation


Parameter:

1.  Fully stainless steel structure.

2.  Hand wheel type of quick-open door structure.

3.  Door safety lock system.

4.  LCD display of working status, touch type key.

5.  Auto discharge the cool air, and steam discharge automatically after sterilization.

6.  Over temperature & over pressure auto-protection.

7.  Safe protection of water lacking.

8.  Self-inflating type seal.

9.  Automatically shut off with beep reminding after sterilization.

10. Easy to operate, safe and reliable.

11. With two stainless steel sterilizing baskets.

12. With drying system.


Use

The vertical pressure steam sterilizers are assembled with heating system, micro-computer controlled system, over heat and over pressure protection system, which are reliable for the sterilizing effects, convenient of operation and energy conservation. They are ideal equipment for clinics, scientific research institutes and other organizations to sterilizer surgical instruments, fabrics, glasses, culture media etc.


Overview:

Technical   DataME-LS-35HDME-LS-50HDME-LS-75HDME-LS-100HD
Chamber volume35L50L75L100L
(φ318×450)mm(φ340×550)mm(φ400×600)mm(φ440×650)mm
 working   pressure                                  0.22MPa
Working   temperature                                  134℃
Max   working pressure                                  0.23Mpa
Heat   average                                  ≤±1℃
Timer                        0~99min或0~99hour59 min
Adjustment   of temperature                                 105~134℃
Power2.5KW/AC220V.50Hz3KW /AC220V.50Hz4.5KW /AC220V.50Hz
Overall   dimension450×450×1010mm510×470×1130 mm560×560×1120 mm540×560×1250 mm
Transport   dimension570×550×1150 mm590×590×1280 mm650×630×1280 mm680×630×1370 mm
G.W/N.W72Kg/ 56Kg88Kg/ 68Kg100Kg/80Kg110/85Kg
